CPP CPE cast film production line
General Introduction
The production line is designed for multi-layer co-extrusion, which can increase the product tension by layering to make the film elastic and enhance the layer tension.
Application
The machine is designed to produce melt-embossed or transparent casting film for various applications.The most optimized design of extruder and T die guarantees high-performance extrusion and various levels of features and automation are available to best meet your needs. It accepts the combination of different resin materials such as PP, EVA, LDPE, LLDPE, and HDPE to include their unique properties.
Project description
Uncoiler semi-automatic/fully automatic film distribution device
Control touch screen, automatic control system
Feeding Continuous automatic weighing system,
Weight mixing control system, dust removal system
Extruder Ø75, Ø100, Ø120, Ø150, Ø180
Material PP / PLA / PET / PC / PE
Speed 250m/min (maximum)
Thickness 0.012mm to 0.15mm
Sheet width 600-3000 mm
Output 150-800kg/hour
Customization can provide high capacity
