Structural features
The main components such as screw, barrel, screen changer and die head are made of high-quality alloy steel (38CrMoAlA) and are nitrided, which has the advantages of high hardness, corrosion resistance and long service life. The screw adopts a large aspect ratio, uniform plasticization and good plasticization ability. The screen changer adopts a hydraulic double screen changer, no need to stop the machine to change the screen. The operation is convenient and quick, and the production efficiency is improved. Stable operation, low noise, reliable performance and high quality. Note: Special products can be customized according to requirements!
The main components such as screw, barrel, screen changer and die head are made of high-quality alloy steel (38CrMoAlA) and are nitrided, which has the advantages of high hardness, corrosion resistance and long service life. The screw adopts a large aspect ratio, uniform plasticization and good plasticization ability. The screen changer adopts a hydraulic double screen changer, no need to stop the machine to change the screen. The operation is convenient and quick, and the production efficiency is improved. Stable operation, low noise, reliable performance and high quality. Note: Special products can be customized according to requirements!
Main structural parameters
Production materials: PP, PS, HIPS, PE
Sheet thickness: 0.3-2mm
Number of layers: 2-3 (AB/ABA)
Maximum extrusion capacity: 180 Kg/h, 250 Kg/h, 350 Kg/h
Diameter of main/secondary screw: §¶100/70 mm, §¶110/80 mm, §¶120/90 mm
Length to diameter ratio "32: 1, 32: 1 32: 1
Roller outer diameter: §¶350 mm, §¶400 mm, §¶450 mm
Main/auxiliary motor power: 45/30 KW, 55/37 KW, 90/45 KW
Total power: 130 KW, 180 KW, 220KW
Weight: 8 T, 10 T, 15 T
Power supply: 380v/50Hz three-phase four-wire
