ABS sheet production line

The plastic sheet machine produced by our company adopts different screw designs and mechanical configurations, which can be used to produce a variety of plastic sheets. (Such as: PP, PE, PS, PC, PET, EVA, PMMA, etc.).

Device model

600/1200/custom

Product width (mm)

500/1100

Product thickness (mm)

0.1—3mm

Maximum linear speed m/min

6-30m

◎Suitable for processing PLA, PET, PP, PS, ABS and other materials.

◎Applicable to 100% fully recycled crushed materials, wide channels, low prices, and support the environmental protection industry.

◎The main machine is equipped with a co-rotating parallel twin-screw extruder with multi-stage exhaust and good plasticizing effect.

◎This machine adopts crystal dehumidifying and drying device for the drying of raw materials, which is suitable for the production of 100% fully recycled crushed materials. (All raw material production does not require drying treatment)

◎Large winding diameter (up to 1200mm); the weight of a single roll can reach 1000kg.

◎The output is as high as 550kg/h without discoloration and good toughness.

◎The whole line adopts man-machine interface display, PLC programmable control, and temperature module management and operation are more convenient.

◎This machine is equipped with a lateral precision feeding device, which can produce sheets of different colors.

◎The screen changer adopts a candle-tube long-term filter, and the screen change time can be extended by 50-100 hours. (Optional)

The content of the whole line

● Extrusion machine: The special design of the screw and the precise temperature control system ensure good plasticization of the rubber and stable extrusion with high output.
● Screen change and mold: Hydraulic quick change device ensures rapid and effective screen change process. The coat-hanger die adopts a multi-runner design to make the rubber evenly distributed over the full width of the mold. The gap between the die lip can be adjusted freely, and the thickness of the sheet can be adjusted accurately.
● Three-roll calender: According to the characteristics of the rubber material, it adopts flat three-roller, inclined three-roller or vertical three-roller, and three-roller temperature control is independent of each other, and the gap is adjusted freely to ensure the calendering effect.
● Cooling guide roller support: equipped with corresponding cold guide rollers, with multiple strong vertical fans, so that the cooling effect is better. It is also equipped with a trimming device to ensure the quality of the edge of the sheet.
● Cutting machine: high-quality alloy cutting edge, imported bearings, to ensure the quality of the cut surface of the sheet and the long-term stable cutting action.
● Winding machine: adopts torque motor and four-axis automatic tension control, which can adjust the speed and winding tension at will to achieve the purpose of flat winding and flatness of the thin plate. With the slitting device, the required product width can be set freely.
